Contract Laminating
Contract Film Lamination
Dunmore's toll laminating capabilities can combine various flexible substrates to create unique laminate constructions up to 5 layers thick. The film laminating process can be done with our various manufacturing assets depending on the needs of your project. Our 50+ years of experience as a film laminating manufacturer gives our customers the flexibility to produce laminates made of various types of materials. In addition to they types of substrates, Dunmore has the film laminating capabilities to produce laminate materials up to 80" wide. Our toll laminating capabilities can be combined with our surface coating and metallizing capabilities to produce a truly unique product.
Common film lamination constructions that we can produce for you include:
- Film to film
- Film to foil
- Film to fabric
Film Laminating Overview
Developing and delivering custom solutions with our partners since 1970, has grown into a portfolio of capabilities as diverse as the industries we serve! Working with you in the strictest of confidence, the Dunmore team works to fully understand your critical performance parameters of your contract laminating project. We are committed to bringing your film lamination design from concept to full commercialization through a systematic, proven approach.
Successfully bonding two or more substrates to exact specifications drives our contract film laminating business. We specialize in producing roll to roll film laminates on a wide variety of flexible web substrates. Our large portfolio of adhesives systems allows our customers to produce laminate construction with challenging materials. Our proven film laminating adhesives for toll laminating projects can withstand extreme conditions and can bond to disparate materials with low surface energy.
Contract Laminating Capabilities
- Substrates
- Production widths: 36” - 80”
- Thickness: .25 - 10 mil
- Adhesive coatings (thermally activated)
- Solvent based and water based
- Adhesive coat weight: up to 40 g/m2
- Film Lamination Constructions
- Bi-laminate
- Tri-laminate
- Inter-leaving
Dry Film Laminating Capabilities
- Substrates
- Production widths: 12” - 62”
- Thickness: .25 - 10 mil
- Multiple Stage Laminate Material
- Inter-leaving
- Ambient Lamination
- Thermal Lamination
- Solventless Lamination
Typical Film Lamination Substrates
- Films
- Acrylic
- Nylon
- Polycarbonate
- Polyester (PET)
- Polyethylene (LDPE)
- Polypropylene (BOPP)
- Polyestyrene
- Polyvinyl Chloride (PVC)
- Synthetic Paper
- Teflon®
- Fluorinated films such as ETFE and DuPont™ Tedlar® film (PVF film)
- Resin Coated Paper
- Fabrics
- Beta cloth
- Fiberglass
- Kevlar
- Nomex®
- Scrims
- Woven & Non-Woven
- Foils
- Aluminum Foil
- Copper Foil
- Stainless Steel Foil
What is Contract Laminating?
The laminating process utilizez industrial machines that are specifically designed to handle and process wide web, flexible substrates in a roll to roll format. Laminating takes two or more substrates and marries them together with an adhesive coating step, producing a composite material. Contract laminating is the same laminating process where you are producing a composite construction, but contract laminating utilizes the customer’s materials. The adhesive system used to marry two or more substrates can be provided by the customer or by the contract laminating company.
Contact Us for More About Our Film Laminating Capabilities
Please Contact Us to find out more about Dunmore's film lamination options.
